Abstract
In this paper, a high flat gain waveguide-fed aperture antenna has been proposed. For this purpose, two layers of FR4 dielectric as superstrates have been located in front of the aperture to enhance the bandwidth and the gain of the antenna. Moreover, a conductive shield, which is connected to the edges of the ground plane and surrounding aperture and superstrates, applied to the proposed structure to improve its radiation characteristics. The proposed antenna has been simulated with HFSS and optimized with parametric study and the following results have been obtained. The maximum gain of 13.0 dBi and 0.5-dBi gain bandwidth of 25.9 % (8.96 - 11.63 GHz) has been achieved. The 3-dBi gain bandwidth of the proposed antenna is 40.7% (8.07-12.20 GHz), which has a suitable reflection coefficient (<=-10dBi) in whole bandwidth. This antenna comprises a compact size of (1.5 lambda x1.5 lambda), easy structure and low-cost fabrication.
