Abstract
The porous structure of the electrodes in redox flow batteries (RFBs) plays a critical role in their performance. We develop a framework for understanding the coupled transport and reaction processes in electrodes by combining lattice Boltzmann modelling (LBM) with experimental measurement of electrochemical performance and X-ray computed tomography (CT). 3D pore-scale LBM simulations of a non-aqueous RFB are conducted on the detailed 3D microstructure of three different electrodes (Freudenberg paper, SGL paper and carbon cloth) obtained using X-ray CT. The flow of electrolyte and species within the porous structure as well as electrochemical reactions at the interface between the carbon fibers of the electrode and the liquid electrolyte are solved by a lattice Boltzmann approach. The simulated electrochemical performances are compared against the experimental measurements with excellent agreement, indicating the validity of the LBM simulations for predicting the RFB performance. Electrodes featuring one single dominant peak (i.e., Freudenberg paper and carbon cloth) show better electrochemical performance than the electrode with multiple dominant peaks over a wide pore size distribution (i.e., SGL paper), whilst the presence of a small fraction of large pores is beneficial for pressure drop. This framework is useful to design electrodes with optimal microstructures for RFB applications.
