Abstract
A new nonlinear, charge-conservative, dynamic electro-thermal compact model for LDMOS RF power transistors is described in this paper. The transistor is characterized using pulsed I-V and S-parameter measurements, to ensure isothermal conditions. The intrinsic model current and charge sources are obtained by integration of the real and imaginary components, respectively, of the small-signal Y-parameters: this yields a charge-conservative model by design. A thermal sub-circuit is used to introduce dynamic thermal dependence, and thermal threshold voltage shift is built in. DC and large-signal validation of the model is presented. © 2008 IEEE.
